Do you really want your wife reminding you of those crooked tiles for the next two decades? Get yourself a cross line laser and lay out your bathroom floor perfectly the first time.

Attach it to almost anything you can think of. Choose between platforms. Adjust it to within 3 degrees of level then let it self-level. No more worrying about inaccurate spirit level settings.

Drill the steel backplate into the wall then use the magnetic bracket to firmly attach your laser level green to your wall or roof. Use the fine adjustment base to get that perfect line on your wall.

Durable. Designed for indoors and outdoors use. Don¡¯t swim with it in a pool or take it into a sandstorm. Will be fine with a bit of water. Even ruggedised against being dropped too.

Key Features:

• 4D 16/12/8-Line laser
• Automatic leveling system
• 2mm Bright beam
• 360¡ã Rotatable base
• IP54 Waterproof
• Wear-resistant and dust-proof
• Thickened stable metal base
• Shockproof and shatter-proof
• Portable storage bag
• Wide applications

Specifications

• Light colour: Green Light
• Line: 16/12/8 Line
• Lifting platform: 28-90mm
• Laser light source: Wavelength 532nm
• Horizontal/Vertical accuracy: ¡À 2mm/10m
• Auto-leveling range: ¡À3¡ã
• Waterproof grade: IP-54
• Working range: About 25m in diameter
• Green light operating temperature: -5?~50?
• Continuous operating time: About 4 Hours
• Power: 100-240V~50/60Hz 0.5A Plug charger
• Battery capacity: 2400mAh
• Colour: Yellow
• Dimension:
  Level: 13cm x 10cm x 12.5cm (L x W x H)
  Iron panel: 6cm x 10cm (L x W)
  Magnetic wall mounted bracket: 6.5cm x 8.5cm x 15cm (L x W x H)
  Lifting platform: 9cm x 9cm x 2.8cm~9cm (lowest height 2.8cm, highest height 9cm)
  Fine adjustment base: 7cm x 7cm x 6cm (L x W x H)
  Tool bag: 22.5 cm x19.5cm x14.5cm (L x W x H)

Package Contents

• 1x 4D16-Line Laser Level
• 1x Lifting Platform
• 1x Fine Adjustment Base
• 1x Battery
• 1x Magnetic Wall Mounted Bracket
• 1x Steel Backplate
• 1x Level Clamp
• 1x Tool Bag
• 1x Battery Recharger
• 1x Instruction Manual

(Picture in instruction manual is for reference only)

Specifications

• Usage: Packaging & Tools
